DAC8311IDCKR

Part No DAC8311IDCKR
Manufacturer Texas Instruments
Catalog Data Acquisition - Digital to Analog Converters (DAC)
Description 1.8V to 5.5V, 80mA, 14- and 16-Bit, Low-Power, Single-Channel, DIGITAL-TO-ANALOG CONVERTERS in SC70 Package
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Resolution 14
Number of D/A Converters 1
Settling Time 10μs
Output Type Voltage - Buffered
Data Interface SPI, DSP
Reference Type Supply
Operating Supply Voltage 2 V ~ 5.5 V
Voltage - Supply, Digital 2 V ~ 5.5 V
INL/DNL (LSB) ±1, ±0.125
Architecture String DAC
Operating Temperature Range -40°C ~ 125°C
Package 6-TSSOP, SC-88, SOT-363
Manufacturer Package SC-70-6
Win Source Part Number 1166656-DAC8311IDCKR
Manufacturer Homepage www.ti.com
Family Name DAC8311
Introduction Date May 01, 2008
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DAC8311IDCKR CAD Model

Description

Texas Instruments DAC8311IDCKR Digital-to-Analog Converter

The DAC8311IDCKR from Texas Instruments is a highly precise 16-bit digital-to-analog converter (DAC) designed to deliver exceptional performance in a compact package. This device is part of Texas Instruments' extensive range of data converters that offer a balance of speed, power efficiency, and resolution to meet the needs of a variety of applications.

Encased in an SC70-6 package, the DAC8311IDCKR is particularly suitable for space-constrained applications. It operates on a single supply voltage ranging from 2.7V to 5.5V, making it versatile for both 3V and 5V systems. The low power consumption of this DAC makes it ideal for battery-powered devices and portable equipment.

One of the standout features of the DAC8311IDCKR is its integrated precision output amplifier. This enables the DAC to drive the output voltage to both ground and the positive supply rail, providing a full-scale output swing that is highly desirable in many system designs. The device also boasts a monotonic output over the entire temperature range, ensuring reliable and consistent performance in various operating conditions.

With its internal reference, the DAC8311IDCKR maintains a tight accuracy, eliminating the need for external calibration in most scenarios. Its digital interface is simple and straightforward, supporting a SPI-compatible serial input that can be easily interfaced with a wide range of microcontrollers and digital systems.

Applications for the DAC8311IDCKR are diverse and include industrial automation, process control, data acquisition systems, and portable instrumentation. Its high-resolution output and low power consumption make it particularly well-suited for precision control tasks where stability and accuracy are paramount.

In summary, the Texas Instruments DAC8311IDCKR is a high-performance, 16-bit DAC that provides a reliable and accurate analog output in a small form factor. Its ease of integration, low power requirements, and robust feature set make it an excellent choice for designers looking to incorporate a high-quality DAC into their systems.
