Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - Full, Half-Bridge Drivers
Mfr Texas Instruments
Series NexFET™
Package Tape & Reel
Output Configuration Half Bridge (3)
Applications Synchronous Buck Converters
Interface PWM
Load Type Inductive, Capacitive
Technology Power MOSFET
Current - Output / Channel 50A
Current - Peak Output 75A
Voltage - Supply 4.5V ~ 5.5V
Voltage - Load 4.5V ~ 16V
Temperature Range - Operating -40°C ~ 125°C (TJ)
Features Bootstrap Circuit
Fault Protection Shoot-Through
Mounting SMD (SMT)
Package / Case 18-PowerTFDFN
Supplier Device Package 18-VSON (5x4)
Base Product Number CSD95495
MSL Level 2 (1 Year)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 296-CSD95495QVMTCT,296-CSD95495QVMTTR,296-CSD95495QVMTDKR,CSD95495QVMT-ND
Standard Package 250
Win Source Part Number 996500-CSD95495QVMT
Ultra Librarian 3D Model Ultra Librarian CSD95495QVMT CAD Model

Description

Introducing the CSD95495QVMT NexFET™ Power Block from Texas Instruments

The CSD95495QVMT is a state-of-the-art power solution designed by Texas Instruments to meet the demands of high-performance power systems. This innovative product is part of TI's NexFET™ power block lineup and is specifically engineered to deliver high efficiency and power density in a compact, integrated package.

The CSD95495QVMT combines two asymmetric NexFET™ MOSFETs in a single package, optimizing the power block for synchronous buck applications. The power stage integrates a high-side and a low-side MOSFET, which are carefully matched to minimize dead-time and power losses, thereby enhancing overall system efficiency.

With its advanced package design, the CSD95495QVMT provides exceptional thermal performance and a reduced footprint on the PCB. This makes it an ideal choice for space-constrained applications such as high-density power supplies, computing, and telecom infrastructure.

Key features of the CSD95495QVMT include:

  • High Performance: With its low R<sub>DS(on) values and optimized gate charge, the CSD95495QVMT minimizes conduction and switching losses, offering superior performance in power conversion applications.
  • Integrated Design: The integration of high-side and low-side MOSFETs simplifies the design process, reduces component count, and saves valuable board space.
  • Enhanced Power Density: The compact QFN package with a 5x6 mm footprint enables high power density, which is crucial for modern power supply designs.
  • Thermal Management: The CSD95495QVMT is designed with excellent thermal characteristics, ensuring reliable operation even under high power and temperature conditions.
  • Flexibility: The power block is optimized for 5V gate drive applications, providing design flexibility and compatibility with a wide range of controllers and drivers.

Whether you're designing power modules for servers, gaming consoles, or advanced computing systems, the CSD95495QVMT offers a robust, efficient, and compact solution. Texas Instruments' commitment to innovation ensures that products like the CSD95495QVMT continue to push the boundaries of power design, offering engineers the tools they need to create cutting-edge technologies for an ever-evolving market.

For detailed specifications, application notes, and design resources, visit the Texas Instruments website to learn more about the CSD95495QVMT NexFET™ Power Block and how it can be integrated into your next high-performance power solution.
