Same model may have multiple batches, images only for reference.
T92S7D12-48 Real Image
Same model may have multiple batches, images only for reference.

T92S7D12-48

Part No T92S7D12-48
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE DPST 30A 48V / Power Relay 48VDC 30A DPST-NO(52.32mm 34.54mm 30.73mm) THT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Series T92
Packaging Bulk
Relay Type General
Coil Type Non Latching
Coil Current 35.4mA
Coil Voltage 48VDC
Contact Form DPST (2 Form A)
Contact Rating (Current) 30A
Switching Voltage 277VAC, 28VDC - Max
Turn On Voltage (Maximum) 36 VDC
Turn Off Voltage (Minimum) 4.8 VDC
Operate Time 15ms
Release Time 15ms
Features Insulation - Class F, Sealed - Fully
Mounting Style Through Hole
Termination Style PC Pin
Contact Material Silver Cadmium Oxide (AgCdO)
Coil Power 1.7 W
Coil Resistance 1.39 kOhms
Operating Temperature Range -55°C ~ 85°C
Win Source Part Number 796206-T92S7D12-48
Popularity Medium
Supply and Demand Status Limited
Family Name T92
Introduction Date January 01, 2000
ECCN EAR99
Country of Origin China
Halogen Free Not Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian T92S7D12-48 CAD Model

Description

The TE Connectivity Potter & Brumfield Relays T92S7D12-48 is a DPST (2 Form A) general purpose relay designed for use in a variety of applications from TE Connectivity Potter & Brumfield Relays.

  • Coil Voltage: 48VDC
  • Contact Rating: 30A
  • Supply and Demand Status: Limited
  • Insulation: Class F
  • Sealing: Fully Sealed
  • Release Time: 15ms
  • Operate Time: 15ms
