Same model may have multiple batches, images only for reference.
MT228115 Real Image
Same model may have multiple batches, images only for reference.

MT228115

Part No MT228115
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr TE Connectivity Potter & Brumfield Relays
Series MT, SCHRACK
Package Tray
Product Status Obsolete
Mounting Type Socketable
Coil Voltage 115VAC
Contact Form DPDT (2 Form C)
Contact Rating (Current) 10 A
Switching Voltage 400VAC - Max
Coil Type Non Latching
Features Lighted Indicator, Test Button
Termination Style Plug In, 8 Pin (Octal)
Must Operate Voltage 92 VAC
Must Release Voltage 46 VAC
Operate Time 15 ms
Release Time 10 ms
Temperature Range - Operating -40°C ~ 50°C
Contact Material Silver Nickel (AgNi)
Relay Type General Purpose
Coil Resistance 2 kOhms
Base Product Number MT22
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.49.0075
Win Source Part Number 1314747-MT228115
Ultra Librarian 3D Model Ultra Librarian MT228115 CAD Model

Description

The TE Connectivity Potter & Brumfield Relays MT22 series 1314747-MT228115 is an obsolete power relay.

  • Contact Form: DPDT
  • Contact Rating: 10A
  • Coil Voltage: 115VAC
  • Coil Resistance: 2kOhms
  • Features: Lighted indicator, a test button
  • Termination Style: Plug-in with an 8-pin octal
  • Switching Voltage: 400VAC - Max
  • Release Time: 10ms
  • Socketable: Yes
  • Operating Temperature: -40°C to 50°C
  • Application: General-purpose
