AZ2150-1A-12DE ZETTLER Electronics
Same model may have multiple batches, images only for reference.

AZ2150-1A-12DE

Part No AZ2150-1A-12DE
Manufacturer American Zettler, Inc.
Catalog Power Relays, Over 2 Amps
Description 40A POWER RELAY / General Purpose Relay SPST-NO (1 Form A) 12VDC Coil Through Hole
Datasheet
AZ2150-1A-12DE Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Power Relays, Over 2 Amps
Mfr American Zettler, Inc.
Series AZ2150
Package Box
Product Status Active
Mounting Type Through Hole
Coil Voltage 12VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 40 A
Switching Voltage 300VAC, 30VDC - Max
Coil Current 77.4 mA
Coil Type Non Latching
Termination Style PC Pin
Seal Rating Sealed - Fully
Coil Insulation Class B
Must Operate Voltage 9 VDC
Must Release Voltage 1.2 VDC
Operate Time 12 ms
Release Time 5 ms
Temperature Range - Operating -55°C ~ 85°C
Contact Material Silver Cadmium Oxide (AgCdO)
Relay Type General Purpose
Coil Resistance 155 Ohms
Standard Package 40 pcs
Win Source Part Number 567538-AZ2150-1A-12DE
Ultra Librarian 3D Model Ultra Librarian AZ2150-1A-12DE CAD Model

Description

The AZ2150 Power Relay is a high-quality component used in various applications.

  • Contact Form: SPST-NO (1 Form A)
  • Contact Material: Silver Cadmium Oxide (AgCdO)
  • Coil Voltage: 12VDC
  • Contact Rating: 40 A
  • Operating Temperature: -55°C ~ 85°C
  • Sealed: Yes
  • Manufacturer: American Zettler, Inc.
  • Mounting Type: Through-hole
