Same model may have multiple batches, images only for reference.
T92P7D52-24 Real Image
Same model may have multiple batches, images only for reference.

T92P7D52-24

Part No T92P7D52-24
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays>Power Relays, Over 2 Amps
Mfr TE Connectivity Potter & Brumfield Relays
Series T92
Package Bulk
Mounting Type Chassis Mount
Coil Voltage 24VDC
Contact Form DPST-NO (2 Form A)
Contact Rating (Current) 30 A
Switching Voltage 277VAC - Nom
Coil Current 70.8 mA
Coil Type Non Latching
Termination Style Screw Terminal
Coil Insulation Class F
Must Operate Voltage 18 VDC
Must Release Voltage 2.4 VDC
Operate Time 15 ms
Release Time 15 ms
Temperature Range - Operating -55°C ~ 85°C
Contact Material Silver Cadmium Oxide (AgCdO)
Relay Type General Purpose
Coil Resistance 350 Ohms
Base Product Number T92P7
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.41.0050
Win Source Part Number 1315062-T92P7D52-24
Ultra Librarian 3D Model Ultra Librarian T92P7D52-24 CAD Model

Description

The T92P7D52-24 is a DPST-NO power relay from TE Connectivity Potter & Brumfield Relays.

  • Contact Form: DPST-NO
  • Contact Rating: 30 A
  • Switching Voltage: 277VAC - Nom
  • Coil Voltage: 24VDC
  • Coil Resistance: 350 Ohms
  • Coil Current: 70.8 mA
  • Operate Time: 15 ms
  • Release Time: 15 ms
  • Latching: Non-Latching
  • Mounting: Chassis Mount
  • Terminals: Screw
  • Must Operate Voltage: 18 VDC
  • Must Release Voltage: 2.4 VDC
  • Temperature Range: -55°C to 85°C
