PXE3024D15 Real Image
Same model may have multiple batches, images only for reference.

PXE3024D15

Part No PXE3024D15
Manufacturer TDK-Lambda Americas Inc.
Catalog Board Mount Modules
Description 30W DC/DC-Converter 'ECONOLINE' 2 x1.6 1.6kV reg ; V. In: 18-36; V. Out: +/-12; mA. Out: +/-1250
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting SMD (SMT)
Case / Package Module
Current - Output 1 1 A
Depth 40.6 mm
Efficiency 88 %
Features OCP, OVP, SCP
Height 10.16 mm
Isolation Isolated
Isolation Voltage 1.6 kV
Length 50.8 mm
Max Input Voltage 36 V
Maximum Operating Temperature 100 °C
Max Output Current 1 A
Max Power Dissipation 30 W
Min Input Voltage 18 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Outputs 2
Number of Pins 7
Output Power 30 W
Packaging Bulk
RoHS Compliant
Voltage - Output 1 15 V
Voltage - Output 2 -15 V
Width 40.64 mm
Win Source Part Number 1033256-PXE3024D15
Categories Board Mount Modules
Manufacturer TDK-Lambda Americas Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian PXE3024D15 CAD Model

Description

The TDK-Lambda Americas Inc. PXE3024D15 is a 30W, isolated, board mount module with a maximum input voltage of 36V.

  • Power: 30W
  • Features: OCP, OVP, and SCP
  • Outputs: Two
  • Output Voltages: 15V and -15V
  • Efficiency: 88%
  • Maximum Output Current: 1A
  • Mounting: SMD (SMT)
  • Isolation Voltage: 1.6kV
  • RoHS Compliant: Yes
  • Maximum Operating Temperature: 100°C
  • Minimum Operating Temperature: -40°C
  • Dimensions: 50.8mm (length), 40.64mm (width), and 10.16mm (height)
  • Pins: 7
  • Category: Board Mount Modules
