Same model may have multiple batches, images only for reference.

MGS15243R3

Name: MGS15243R3
Brand: Cosel USA, Inc.
SKU: 1231491
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	MGS15243R3
Manufacturer	Cosel USA, Inc.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 3.3V / Isolated Module DC DC Converter 1 Output 3.3V 4A 18V - 36V Input
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount>DC DC Converters
Mfr	Cosel USA, Inc.
Series	MGS (15W)
Package	Box
Type	Isolated Module
Number of Outputs	1
Voltage - Input (Min)	18V
Voltage - Input (Max)	36V
Voltage - Output 1	3.3V
Current - Output (Max)	4A
Voltage - Isolation	1.5 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	89%
Mounting Type	Through Hole
Package / Case	6-DIP Module
Dimension	1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
Base Product Number	MGS15243
MSL Level	Not Applicable
ECCN	EAR99
HTSUS	8504.40.9580
Other Names	1776-1372
Standard Package	1
Win Source Part Number	1231491-MGS15243R3
Ultra Librarian 3D Model	Ultra Librarian MGS15243R3 CAD Model

Alternative Products

Description

The MGS15243R3 is a 15W isolated module DC-DC converter from Cosel USA, Inc.

Features: Remote On/Off, OCP
Application: ITE (Commercial)
Voltage Isolation: 1.5 kV
Output: One
Maximum Current Output: 4A
Input Voltage: 18V to 36V
Output Voltage: 3.3V
Efficiency: 89%
Mounting Type: Through Hole
Package/Case: 6-DIP Module
Operating Temperature Range: -40°C to 85°C (with derating)
Dimension: 1.00" L x 1.00" W x 0.39" H (25.4mm x 25.4mm x 9.9mm)
