Same model may have multiple batches, images only for reference.
PH75S110-5 Real Image
Same model may have multiple batches, images only for reference.

PH75S110-5

Part No PH75S110-5
Manufacturer TDK-Lambda Americas Inc.
Catalog Power Supplies Board Mount DCDC Converters
Description DC DC CONVERTER 5V 75W / Isolated Module DC DC Converter 1 Output 5V 15A 82V - 185V Input
Datasheet
PH75S110-5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount>DC DC Converters
Mfr TDK-Lambda Americas Inc
Series PH-S (75W)
Package Bulk
Product Status Obsolete
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 82V
Voltage - Input (Max) 185V
Voltage - Output 1 5V
Current - Output (Max) 15A
Power (Watts) 75 W
Voltage - Isolation 3 kV
Applications ITE (Commercial)
Features Remote On/Off, OCP, OVP
Temperature Range - Operating -20°C ~ 85°C
Mounting Type Through Hole
Package / Case Module
Dimension 3.85" L x 1.61" W x 0.50" H (86.0mm x 41.0mm x 12.7mm)
Control Features Enable, Active Low
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.40.9580
Other Names PH75S1105
Standard Package 1
Win Source Part Number 1232518-PH75S110-5
Ultra Librarian 3D Model Ultra Librarian PH75S110-5 CAD Model

Description

The PH75S110-5 is a power supply component manufactured by TDK-Lambda Americas Inc.

  • Power: 75W
  • Type: Isolated Module
  • Features: Remote On/Off, OCP, OVP
  • Package: Bulk
  • Standard Package: 1
  • Application: ITE (Commercial)
  • Voltage Isolation: 3 kV
  • Outputs: 1
  • Output Current: 15A
  • Voltage Input: 82V to 185V
  • Voltage Output: 5V
  • Mounting Type: Through-Hole
  • Package/Case: Module
  • Operating Temperature: -20°C to 85°C
  • Status: Obsolete
