DLFL-0147-25D2 Schurter Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

DLFL-0147-25D2

Part No DLFL-0147-25D2
Manufacturer Schurter Inc.
Catalog Common Mode Chokes
Description CMC 25A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Number of Lines 2
Current Rating (Max) 25A
DC Resistance (DCR) (Max) 10mOhm
Voltage Rating - AC 440V
Temperature Range - Operating -25°C ~ 100°C
Mounting Type Through Hole
Size / Dimension 1.969" L x 1.969" W (50.00mm x 50.00mm)
Case / Package Radial
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1531952-DLFL-0147-25D2
Ultra Librarian 3D Model Ultra Librarian DLFL-0147-25D2 CAD Model

Description

N
