9050JCK70V14 Schneider Electric – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

9050JCK70V14

Part No 9050JCK70V14
Manufacturer Schneider Electric
Catalog Time Delay Relays
Description RELAY TIME DELAY 999HR 10A 240V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Socketable
Relay Type Mechanical Relay
Function Programmable (Multi-Function)
Circuit DPDT (2 Form C)
Delay Time 0.05 Sec ~ 999 Hrs
Contact Rating @ Voltage 10A @ 240VAC
Voltage - Supply 24VAC
Termination Style Plug In
Timing Adjustment Method Thumbwheel Switches
Timing Initiate Method Input Voltage, Trigger Signal
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1550928-9050JCK70V14
Ultra Librarian 3D Model Ultra Librarian 9050JCK70V14 CAD Model

Description
