Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr ON Semiconductor
Series *
Package Bulk
Product Status Active
Standard Package 10,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 327853-SMBD1107LT3
Ultra Librarian 3D Model Ultra Librarian SMBD1107LT3 CAD Model

Description

The SMBD1107LT3 from ON Semiconductor is a high-performance, surface-mount Schottky barrier diode designed for applications requiring a balance of low forward voltage drop and high surge current capability. This diode is housed in a compact SMB package, making it ideal for space-constrained applications while providing robust performance.

Key Features

  • Low Forward Voltage: The SMBD1107LT3 offers a low forward voltage drop, which enhances system efficiency by reducing power loss during operation.
  • High Surge Capability: Designed to withstand high surge currents, this diode is suitable for applications that experience transient over-voltage conditions.
  • Power Dissipation: With a power dissipation rating that ensures reliable operation under varying conditions, this component is built to handle significant energy without compromise.
  • Operating Temperature: The device operates effectively over a wide temperature range, making it versatile for different environments.
  • RoHS Compliant: The SMBD1107LT3 is compliant with RoHS standards, minimizing the environmental impact by avoiding the use of certain hazardous materials.

Applications

The ON Semiconductor SMBD1107LT3 is suitable for a variety of applications, including:

  • Power supply rectification
  • Freewheeling diodes in converters and motor control circuits
  • Reverse voltage protection
  • Switching power supplies
  • DC-DC converters
  • Automotive applications

Product Specifications

Parameter Value Package Type SMB Peak Repetitive Reverse Voltage 70V Average Rectified Forward Current 1A Non-Repetitive Peak Forward Surge Current 40A Operating Junction Temperature Range -55°C to +125°C RoHS Yes

With its robust construction and high reliability, the ON Semiconductor SMBD1107LT3 Schottky barrier diode is an excellent choice for designers seeking a component that offers both efficiency and durability.
