Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 380mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1mA @ 30V
Mounting SMD (SMT)
Case / Package SOD-123L
Operating Temperature - Junction -55°C to 125°C
Win Source Part Number 022380-MBR130LSFT1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Portable Devices, Communications & Networking, Consumer Electronics, Computers & Computer Peripherals
Family Name MBR130LSF
Introduction Date January 09, 2004
ECCN EAR99
Country of Origin China, Malaysia
Halogen Free Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian MBR130LSFT1G CAD Model

Description

ON Semiconductor MBR130LSFT1G Schottky Barrier Rectifier

The MBR130LSFT1G from ON Semiconductor is a state-of-the-art Schottky Barrier Rectifier designed to offer efficient and reliable performance for a diverse range of applications. This compact surface-mount component is engineered to provide low forward voltage drop while maintaining a high current capability, making it an ideal choice for power supply and energy management systems.

Key Features

  • Low Forward Voltage: The device features a low forward voltage drop, which enhances system efficiency by reducing power loss during operation.
  • High Surge Capability: With its robust surge handling capacity, the MBR130LSFT1G is capable of withstanding high surge currents, ensuring reliability under stress conditions.
  • Power Dissipation: Rated at 1.5 watts, this Schottky diode is capable of handling moderate power levels, suitable for a variety of electronic circuits.
  • Reverse Voltage: It has a maximum reverse voltage of 30V, which allows it to be used in circuits with moderate voltage requirements.
  • Low Leakage Current: The device exhibits a low leakage current, minimizing power waste when in the reverse bias state.
  • RoHS Compliant: The MBR130LSFT1G is compliant with RoHS standards, ensuring that it is free from hazardous substances and suitable for use in environmentally-sensitive applications.

Applications

The ON Semiconductor MBR130LSFT1G is versatile and can be used in various applications, including:

  • Switching power supplies
  • Converters
  • Free-wheeling diodes
  • Reverse battery protection
  • DC-DC converters
  • Automotive applications

With its robust design and high-performance characteristics, the MBR130LSFT1G is well-suited for use in high-frequency and energy-sensitive circuits where efficiency is paramount. Its small footprint makes it an excellent choice for compact electronic assemblies, and its reliability ensures long-term operation even in demanding environments.

Whether you're designing a power supply unit, working on automotive electronics, or developing energy management systems, the MBR130LSFT1G Schottky Barrier Rectifier from ON Semiconductor is a component that offers both performance and reliability.
