Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr ON Semiconductor
Package Tape & Reel
Product Status Obsolete
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 20 V
Current - Average Rectified (Io) 500mA
Voltage - Forward (Vf) (Max) @ If 385 mV @ 500 mA
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 250 µA @ 20 V
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package SOD-123
Base Product Number MBR0520
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 759741-MBR0520LT1
Ultra Librarian 3D Model Ultra Librarian MBR0520LT1 CAD Model

Description

ON Semiconductor MBR0520LT1 Schottky Barrier Rectifier

The MBR0520LT1 is a robust Schottky barrier rectifier designed by ON Semiconductor, renowned for its high efficiency and reliability in power management applications. This surface-mount diode is engineered to offer low forward voltage drop while providing superior switching performance, making it an ideal choice for compact, high-frequency circuits.

Constructed with ON Semiconductor's state-of-the-art technology, the MBR0520LT1 boasts a peak repetitive reverse voltage (Vrrm) of 20 volts and a non-repetitive peak surge current (Ipp) rating that ensures it can handle high surge events. With a continuous forward current (If) of 0.5 amperes, this diode is capable of supporting moderate power requirements in a variety of electronic devices.

The device comes in a small, power-efficient SOD-123 package, which is not only space-saving but also allows for easy integration into PCB designs. The MBR0520LT1's compact footprint is especially beneficial for portable and space-constrained applications where efficiency and board real estate are of paramount importance.

Key features of the MBR0520LT1 include its low power loss and low thermal resistance, which contribute to a reduced operating temperature and enhanced overall system longevity. The Schottky barrier design ensures fast switching with minimal losses, which is crucial for power conversion applications such as DC-DC converters, freewheeling diodes, and polarity protection circuits.

ON Semiconductor's commitment to environmental sustainability is reflected in the MBR0520LT1's compliance with RoHS (Restriction of Hazardous Substances) directives, making it a safe choice for manufacturers looking to create eco-friendly products. Moreover, its guard ring construction for transient protection adds an extra layer of reliability, safeguarding sensitive electronic components against voltage spikes and other electrical anomalies.

In summary, the MBR0520LT1 Schottky barrier rectifier from ON Semiconductor is a high-performance, energy-efficient solution for a wide range of power management challenges. Its compact size, robust surge capability, and fast switching speeds make it a versatile component that can enhance the performance and durability of your electronic designs.
