Products specifications Report Issue?

Manufacturer Maxim Integrated
Win Source Part Number 1214748-MAX6946CAWE
Manufacturer Homepage www.maxim-ic.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX6946CAWE CAD Model

Description

Maxim Integrated's MAX6946CAWE: A Versatile LED Driver

The MAX6946CAWE from Maxim Integrated is a high-performance, 10-port LED driver designed to provide a flexible and efficient solution for controlling multiple LEDs. This integrated circuit (IC) is specifically tailored for applications that require precise control over individual LEDs, such as status indicators, backlights, and alphanumeric displays.

With its I²C-compatible serial interface, the MAX6946CAWE allows for seamless integration into a wide range of systems, enabling easy communication with microcontrollers or other digital devices. The device supports a 5.5V supply voltage, making it versatile for various operating environments. Its 10 ports can be individually adjusted for current control, allowing for brightness levels to be finely tuned to meet the specific needs of any application.

One of the standout features of the MAX6946CAWE is its built-in PWM (pulse-width modulation) engine, which supports 256-step dimming. This feature ensures smooth and flicker-free brightness control of the LEDs, enhancing the user experience and expanding the range of possible lighting effects that can be achieved with the device.

The MAX6946CAWE also includes several safety features that protect both the IC and the LEDs. Over-temperature protection ensures that the device operates within safe temperature limits, while open-circuit detection helps to identify any potential issues with the LED connections. These features contribute to the overall reliability and longevity of the system.

Designed with space-constrained applications in mind, the MAX6946CAWE is available in a compact 16-pin QSOP package, making it an ideal choice for portable devices or any other applications where board space is at a premium. Its low standby current also helps to extend battery life in portable applications.

In summary, the MAX6946CAWE from Maxim Integrated is a powerful and flexible LED driver that can be used in a wide array of lighting applications. Its precise control, safety features, and compact design make it an excellent choice for designers looking to enhance their LED lighting solutions.
