SS30V-R250092

Part No SS30V-R250092
Manufacturer Kemet
Catalog Common Mode Chokes
Description CMC 9.2MH 2.5A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 9.2 mH @ 1 kHz
Current Rating (Max) 2.5A
DC Resistance (DCR) (Max) 160mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -40°C ~ 120°C
Mounting Type Through Hole
Size / Dimension 1.220" L x 0.886" W (31.00mm x 22.50mm)
Height (Max) 1.299" (33.00mm)
Case / Package Vertical, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530635-SS30V-R250092
Ultra Librarian 3D Model Ultra Librarian SS30V-R250092 CAD Model
