IPW60R120C7XKSA1 Infineon Technologies
Same model may have multiple batches, images only for reference.

IPW60R120C7XKSA1

Part No IPW60R120C7XKSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 600V 19A TO247-3 / N-Channel 600 V 19A (Tc) 92W (Tc) Through Hole PG-TO247-3
Datasheet
IPW60R120C7XKSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr Infineon Technologies
Series CoolMOS™ C7
Package Tube
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 600 V
Current - Continuous Drain (Id) @ 25°C 19A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 120mOhm @ 7.8A, 10V
Vgs(th) (Max) @ Id 4V @ 390µA
Gate Charge (Qg) (Max) @ Vgs 34 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 1500 pF @ 400 V
Power Dissipation (Max) 92W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Supplier Device Package PG-TO247-3
Package / Case TO-247-3
Base Product Number IPW60R120
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Other Names SP001385060,INFINFIPW60R120C7XKSA1,2156-IPW60R120C7XKSA1
Standard Package 240
Win Source Part Number 1001666-IPW60R120C7XKSA1
Ultra Librarian 3D Model Ultra Librarian IPW60R120C7XKSA1 CAD Model

Description

The IPW60R120C7XKSA1 is a N-channel MOSFET transistor from Infineon Technologies.

  • Series: CoolMOS C7
  • Package: TO-247-3
  • Drain to Source Voltage: 600 V
  • Continuous Drain Current: 19A @ 25°C
  • Rds On: 120mOhm @ 7.8A and 10V
  • Gate Charge: 34 nC @ 10 V
  • Input Capacitance: 1500 pF @ 400 Vds
  • Operating Temperature: -55°C to 150°C
  • Power Dissipation: 92W (Tc)
  • Maximum Gate-Source Voltage: ±20V
  • Applications: Power supplies, motor control, and lighting
