149E Hammond Manufacturing – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Impedance - Primary (Ohms) 300
Impedance - Secondary (Ohms) 120, 30/30
DC Resistance (DCR) - Primary 41Ohm
DC Resistance (DCR) - Secondary 10Ohm
Transformer Type Economical Open Type
Frequency Range 200Hz ~ 15kHz
Frequency Response ±1dB
Insertion Loss 0.5dB
Power Level 200mW
Mounting Type Through Hole
Size / Dimension 1.060" L x 0.820" W (26.92mm x 20.83mm)
Height - Seated (Max) 0.820" (20.83mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1544976-149E
Ultra Librarian 3D Model Ultra Librarian 149E CAD Model
