Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Fans, Thermal Management - Fans - DC Brushless Fans (BLDC)
Mfr Delta Electronics
Series PFB
Package Bulk
Product Status Active
Voltage - Rated 24VDC
Size / Dimension Square - 92mm L x 92mm H
Width 38.00mm
Air Flow 153.5 CFM (4.30m³/min)
Static Pressure 1.449 in H2O (360.9 Pa)
Bearing Type Ball
Fan Type Tubeaxial
Features Locked Rotor Protection
Noise 64.0dB(A)
Power (Watts) 21.84 W
RPM 7000 RPM
Termination 2 Wire Leads
Ingress Protection -
Temperature Range - Operating 14 ~ 140°F (-10 ~ 60°C)
Approval Agency CE, CSA, UL, VDE
Weight 0.553 lb (250.84 g)
Current Rating (Amps) 0.910A
Voltage Range 14 ~ 26.4VDC
Material - Frame Plastic
Material - Blade Plastic
Lifetime @ Temp. 50000 Hrs @ 40°C
Base Product Number PFB0924
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8414.59.6590
Win Source Part Number 1368403-PFB0924UHE
Ultra Librarian 3D Model Ultra Librarian PFB0924UHE CAD Model

Description

The PFB0924UHE is a 92mm square DC brushless fan from Delta Electronics.

  • Voltage: 24VDC
  • Current: 0.910A
  • Power: 21.84W
  • Maximum Noise Level: 64.0dB(A)
  • Lifetime: 50,000 hours @ 40°C
  • Operating Temperature: 14°F to 140°F (-10°C to 60°C)
  • Series: PFB
  • Packaging: Bulk
  • Protection: Locked Rotor Protection
  • Bearing Type: Ball
  • Approvals: CE, CSA, UL, and VDE
  • Application: Thermal Management
