Manufacturer Conec
Packaging Bulk
Connector Style D-Sub
Connector Type Plug, Male Pins
Number of Positions 50
Number of Rows 3
Shell Size, Connector Layout 5 (DD, D)
Contact Type Signal
Mounting Style Board Edge, Through Hole, Right Angle
Flange Feature Housing/Shell (4-40)
Termination Solder
Features Board Lock, Grounding Indents
Shell Material, Finish Steel, Tin Plated
Contact Finish Gold
Contact Finish Thickness 8.00μin (0.203μm)
Ingress Protection IP20
Material Flammability Rating UL94 V-0
Current Rating (Amps) 7.5A
Temperature Range - Operating -55°C ~ 125°C
Voltage Rating 125V
Color Black
Dielectric Material Polybutylene Terephthalate (PBT), Glass Filled
Contact Material Copper Alloy
Backset Spacing 0.283" (7.20mm)
Manufacturer Pack Quantity 30
MSL Level 1 (Unlimited)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810819-163A18569X
Ultra Librarian 3D Model Ultra Librarian 163A18569X CAD Model

Description

The Conec 810819-163A18569X is a 50-position male plug D-sub connector from Conec.

  • Mounting Style: Board Edge, Through Hole, Right Angle
  • Termination: Solder
  • Contact Material: Copper Alloy
  • Contact Finish: Gold
  • Contact Finish Thickness: 8.00μin (0.203μm)
  • Shell Material: Steel
  • Shell Plating: Tin
  • Dielectric Material: Polybutylene Terephthalate (PBT), Glass Filled
  • Voltage Rating: 125V
  • Ingress Protection: IP20
  • Operating Temperature Range: -55°C ~ 125°C
  • Current Rating: 7.5A
  • Manufacturer Pack Quantity: 30
