HSMS-2802-TR1G Broadcom Limited HSMS-2802-TR1G real image
Same model may have multiple batches, images only for reference.
HSMS-2802-TR1G Broadcom Limited HSMS-2802-TR1G real image
HSMS-2802-TR1G Broadcom Limited HSMS-2802-TR1G real image
Same model may have multiple batches, images only for reference.

HSMS-2802-TR1G

Part No HSMS-2802-TR1G
Manufacturer Broadcom Limited
Catalog RF Diodes
Description DIODE SCHOTTKY RF SER 70V SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Diode Type Schottky - 1 Pair Series Connection
Voltage - Peak Reverse (Max) 70V
Current - Max 1A
Capacitance @ Vr, F 2pF @ 0V, 1MHz
Resistance @ If, F 35 Ohm @ 5mA, 1MHz
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-23-3
Win Source Part Number 017049-HSMS-2802-TR1G
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name HSMS-2802
Introduction Date April 01, 2004
ECCN EAR99
Country of Origin Malaysia, Thailand
Halogen Free Compliant
Estimated EOL Date Obsolete
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian HSMS-2802-TR1G CAD Model

Description

The HSMS-2802-TR1G is a Schottky diode pair manufactured by Broadcom Limited with the following specifications:

  • Peak Reverse Voltage: 70V
  • Maximum Current: 1A
  • Capacitance: 2pF at 0V, 1MHz
  • Resistance: 35 Ohm at 5mA, 1MHz
  • Package: SOT-23-3
  • Quantity per Package: 3k pcs
  • Operating Temperature Range: 150°C
  • Supply and Demand Status: Balanced
