Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - LED Drivers
Mfr Analog Devices Inc.
Series True Color PWM™
Package Tube
Product Status Obsolete
Type DC DC Controller
Topology Step-Down (Buck), Step-Up (Boost)
Internal Switch(s) No
Number of Outputs 1
Voltage - Supply (Min) 4.7V
Voltage - Supply (Max) 60V
Voltage - Output 0V ~ 60V
Frequency 200kHz ~ 700kHz
Dimming Analog, PWM
Applications Automotive, Lighting
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case 38-TFSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package 38-TSSOP-EP
Base Product Number LT3791
Standard Package 1 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN OBSOLETE
HTSUS 0000.00.0000
Win Source Part Number 845540-LT3791EFE
Ultra Librarian 3D Model Ultra Librarian LT3791EFE CAD Model

Description

Product Overview: LT3791EFE from Analog Devices Inc.

The LT3791EFE is a high-performance DC/DC controller designed by Analog Devices Inc. to cater to the demanding requirements of power conversion and management applications. This robust component is tailored for systems that need to efficiently convert power from a wide input voltage range to a lower, regulated output voltage with high power levels.

Key Features

  • Wide Input Voltage Range: The LT3791EFE operates over a broad input voltage range of 4.7V to 60V, making it versatile for use in various applications, including automotive, industrial, and telecommunications systems.
  • High Efficiency: With its advanced design, this controller achieves high efficiency, which is critical for reducing heat dissipation and improving system reliability.
  • Constant-Current and Constant-Voltage Regulation: It can be configured for constant-current/constant-voltage regulation, making it ideal for battery charging and LED driving applications where precise control is necessary.
  • Robust Thermal Performance: The LT3791EFE is available in a thermally efficient TSSOP-38 package, ensuring adequate heat dissipation for reliable operation under high power conditions.
  • Multiple Topologies Supported: It supports boost, buck-boost, and SEPIC topologies, providing design flexibility to meet specific circuit requirements.

Applications

  • Automotive and Industrial Power Systems
  • Battery-Powered Equipment
  • Power LED Drivers
  • General Purpose High Power DC/DC Converters

The LT3791EFE integrates several protection features, including overvoltage, overcurrent, and thermal shutdown, which contribute to the longevity and safety of the end application. Its precision current sensing and programmable frequency (up to 1MHz) allow for fine-tuning performance to match specific design needs.

Analog Devices Inc. has a reputation for creating high-quality, reliable components, and the LT3791EFE is no exception. It is engineered to simplify the design process while delivering performance that helps enhance the efficiency and robustness of power systems. Whether for driving high-brightness LEDs, charging batteries, or managing power in sensitive electronics, the LT3791EFE is a versatile and dependable choice for designers looking to optimize their power solutions.
