ALFT-03A-8 Abracon LLC – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ALFT-03A-8

Part No ALFT-03A-8
Manufacturer Abracon LLC
Catalog Common Mode Chokes
Description CMC 5.5MH 1A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 5.5 mH @ 1 kHz
Current Rating (Max) 1A
DC Resistance (DCR) (Max) 750mOhm
Voltage Rating - DC 250V
Temperature Range - Operating -25°C ~ 85°C
Mounting Type Through Hole
Size / Dimension 0.941" L x 0.709" W (23.90mm x 18.00mm)
Height (Max) 0.850" (21.60mm)
Case / Package Vertical, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1530340-ALFT-03A-8
Ultra Librarian 3D Model Ultra Librarian ALFT-03A-8 CAD Model
