SIC403DB Real Image
Same model may have multiple batches, images only for reference.

SIC403DB

Part No SIC403DB
Manufacturer Vishay
Catalog Evaluation Boards - DC/DC & AC/DC (Off - Line)SMPS
Datasheet
SIC403DB Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr Vishay Siliconix
Series microBUCK®
Package Box
Main Purpose DC/DC, Step Down with LDO
Outputs and Type 2, Non-Isolated
Current - Output 6A, 200mA
Voltage - Input 3V ~ 28V
Regulator Topology Buck
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part SiC403
Base Product Number SIC403
Standard Package 1
RoHS Status Not applicable
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284142-SIC403DB
Ultra Librarian 3D Model Ultra Librarian SIC403DB CAD Model

Description

The Vishay Siliconix microBUCK® SiC403DB is a fully populated development board that is used for DC/DC step down with LDO applications.

  • Regulator Topology: buck
  • Input Voltage Range: 3V to 28V
  • Outputs: two non-isolated outputs
  • Supplied with: board(s)
  • MSL Level: 1 (Unlimited)
  • HTSUS: 8473.30.1180
  • Description: This development board is ideal for use in various electronic applications.
