F-360U

Part No F-360U
Manufacturer Triad Magnetics
Catalog Power Transformers
Description PWR XFMR LAMINATED 78VA CHAS MT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Laminated Core
Voltage - Primary 115V, 230V
Voltage - Secondary (Full Load) 6.5V, 13V, 19.5V, 26V
Current - Output (Max) 3A
Primary Winding(s) Dual
Secondary Winding(s) Single
Center Tap Yes
Power - Max 78VA
Mounting Type Chassis Mount
Termination Style Wire Leads
Size / Dimension 71.42mm L x 66.68mm W
Height - Seated (Max) 85.73mm
Voltage - Isolation 1500Vrms
Weight 3.5 lbs (1.6 kg)
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1546295-F-360U
Ultra Librarian 3D Model Ultra Librarian F-360U CAD Model
