The TE0720-04-61C33MAS is a SoM (System on Module) manufactured by Trenz Electronic GmbH. This module features a Xilinx Zynq-7000 series SoC (System on Chip), combining a dual-core ARM Cortex-A9 processor with FPGA fabric. It's designed for embedded applications requiring real-time processing, flexible I/O, and custom hardware acceleration. This module simplifies the development process by providing a pre-built, tested, and reliable platform for complex applications.

Applications

• Industrial automation
• Motor control
• Image processing
• Software-defined radio (SDR)
• Embedded vision systems
• Robotics

Features

• Xilinx Zynq-7000 SoC (XC7Z010-1CLG400C)
• Dual-core ARM Cortex-A9 processor
• 512 MB DDR3 SDRAM
• 16 MB SPI Flash memory
• Gigabit Ethernet
• USB 2.0 OTG
• On-board voltage regulators
• 148 FPGA I/O pins
• Compact form factor

Benefits

• Reduces development time and cost by providing a pre-validated platform
• Enables flexible hardware acceleration through the FPGA fabric
• Offers a wide range of connectivity options
• Simplifies integration into existing systems
• Provides a scalable solution for various embedded applications
• Supports Linux and other embedded operating systems

Additional Details

The TE0720-04-61C33MAS SoM offers a comprehensive set of features, including a powerful processing core, ample memory, and a wide range of connectivity options. The Xilinx Zynq-7000 SoC provides a flexible platform for implementing custom hardware accelerators, enabling developers to optimize performance for specific applications. The module is supported by a wide range of development tools and resources, including reference designs, software libraries, and documentation. Its compact form factor and robust design make it suitable for use in harsh environments. The specific FPGA resources and I/O configurations are detailed in the product datasheet.
