The XTR105U is a highly integrated and robust 4-20mA current transmitter from Texas Instruments, designed to work with precision in a wide range of industrial and instrumentation applications. The device is renowned for its reliability and versatility, making it an ideal choice for professionals seeking to develop efficient control systems and monitoring solutions.

Key Features

• Integrated Current Transmitter: The XTR105U includes a current transmitter with a voltage-to-current conversion feature, enabling it to convert a voltage input into a current output, which is less susceptible to noise and loss over long distances.
• Two-Wire Operation: Designed for two-wire systems, this device simplifies power and signal transmission by using the same pair of wires for both purposes, reducing wiring complexity and cost.
• Built-in Sensor Excitation: It comes with an onboard regulated voltage source that can be used to power sensors, eliminating the need for external power supplies for the sensor.
• Flexible Input Range: The XTR105U can accommodate a wide range of input signals, making it compatible with various sensors and input types.
• High Accuracy: Precision laser trimming ensures high accuracy in signal conversion, which is crucial for critical measurement and control applications.
• Temperature Compensation: The device includes temperature compensation features that maintain accuracy over a broad temperature range, making it suitable for harsh environments.
• Protection Features: It is equipped with protection mechanisms against overvoltage and reverse polarity, safeguarding the device and connected components.

Applications

The XTR105U is designed for a variety of industrial applications including:

• Process control systems
• Factory automation
• Instrumentation
• Remote data acquisition
• Smart transmitters

Technical Specifications

With a wide supply voltage range and low quiescent current, the XTR105U is optimized for low-power operation without sacrificing performance. The robust design ensures long-term stability and performance in the demanding conditions typical of industrial environments.

For engineers and designers looking for a reliable current transmitter solution, the XTR105U from Texas Instruments represents a blend of performance, integration, and reliability.
