Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 34 Weeks
Features PFC IC Continuous Conduction (CCM) 18kHz ~ 250kHz 8-SOIC
Manufacturer Texas Instruments
Package Tube
Operating Temperature Range -40°C ~ 125°C
Mounting Surface Mount
Package 8-SOIC (0.154", 3.90mm Width)
Case / Package 8-SOIC
Family Name UCC28180
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number -UCC28180D-NDR, -296-37132-5-ND, 296-37132-5, -296-37132-5
Quantity per package 75
Popularity High
Supply and Demand Status Balance
Win Source Part Number 938067-UCC28180D
Ultra Librarian 3D Model Ultra Librarian UCC28180D CAD Model

Description

The UCC28180D is a versatile and robust Pulse Width Modulation (PWM) controller designed and manufactured by Texas Instruments. This device is specifically engineered to facilitate the development of high-performance power supplies, with a particular emphasis on off-line and DC-to-DC power conversion applications. Its advanced features and design make it suitable for a wide range of power supply topologies, including boost, buck, flyback, and forward converters.

Key Features

  • Wide PWM Frequency Range: The UCC28180D operates at a programmable switching frequency that ranges from 16 kHz to 250 kHz, allowing designers to optimize their power supply for efficiency or size by selecting the appropriate frequency for their application.
  • Advanced Current Mode Control: This technique provides superior transient response, simplified loop compensation, and robust overload protection, enhancing the performance and reliability of the end application.
  • Multi-Mode Operation: The UCC28180D incorporates both continuous conduction mode (CCM) and discontinuous conduction mode (DCM), providing flexibility in addressing various load conditions.
  • High-Efficiency Operation: With its low-startup and operating currents, the UCC28180D maximizes efficiency, which is crucial for energy-saving applications and compliance with energy efficiency standards.
  • Programmable Soft Start: This feature limits inrush current during startup, reducing stress on the power supply components and extending their operational life.
  • Built-in Protection Features: The device includes overcurrent protection, overvoltage protection, and thermal shutdown, which contribute to the overall safety and durability of the power supply.

Applications

The UCC28180D is ideal for a variety of applications, including but not limited to:

  • AC/DC power supplies for consumer electronics
  • LED drivers
  • Power supplies for communication equipment
  • Industrial power systems

Package and Availability

The UCC28180D is available in a compact 8-pin SOIC package, making it suitable for space-constrained applications. Texas Instruments provides comprehensive support for this product, including detailed datasheets, application notes, and design resources to assist engineers in integrating this PWM controller into their designs.
