Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel MOSFET
Supply Voltage - Operating 8 V to 17 V
Logic Voltage - VIL, VIH 1.3V, 2.8V
Current - Peak Output (Source, Sink) 4A, 4A
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 120V
Rise and Fall Time 7.2ns, 5.5ns
Temperature Range - Operating -40°C to 140°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO PowerPad
Win Source Part Number 144823-UCC27211DDAR
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian UCC27211DDAR CAD Model

Description

The UCC27211DDAR is a high-performance, dual-channel driver designed by Texas Instruments, specifically engineered to drive N-channel power MOSFETs and IGBTs. This advanced driver is well-suited for a variety of applications, including motor control, power supply systems, and other power conversion tasks that demand efficient and reliable switching.

Key Features

  • High Peak Output Drive Capability: With a robust peak drive strength of 4 A source and 4 A sink, the UCC27211DDAR is capable of rapidly charging and discharging the gate capacitance of MOSFETs, enabling fast switching speeds and reducing switching losses.
  • Wide Supply Voltage Range: The device operates over a wide supply voltage range from 10 V to 20 V, providing flexibility across different circuit designs and ensuring consistent performance.
  • High-Side and Low-Side Driver: The integrated dual-channel driver includes both a high-side and a low-side output, which can be configured for half-bridge, full-bridge, or push-pull topologies.
  • Robust 3.4-A Peak Sink Current: The UCC27211DDAR is capable of providing a peak sink current of 3.4 A, ensuring effective turn-off of the power device, further improving efficiency.
  • Independent Inputs: Separate inputs for high-side and low-side gates offer design flexibility and the ability to implement dead-time control and protection features.
  • Cross-Conduction Prevention: Built-in cross-conduction prevention logic helps to avoid simultaneous high-side and low-side conduction, protecting the power devices and the load.
  • Extended Temperature Range: The device is designed to operate over an extended industrial temperature range, ensuring reliability and performance under varying environmental conditions.

Applications

The UCC27211DDAR is ideal for a wide array of applications, including:

  • DC to AC Power Inverters
  • DC to DC Converters
  • Motor Drives
  • Switch Mode Power Supplies (SMPS)
  • Renewable Energy Systems
  • High Power LED Lighting

Package and Reliability

The UCC27211DDAR comes in a compact 8-pin SOIC package, allowing for efficient use of PCB space. Its robust design ensures long-term reliability, making it a trusted choice for engineers and designers looking for a high-quality driver solution.
