The TXS0104EPWRG4 is a bidirectional voltage-level translator from Texas Instruments, designed to bridge the gap between devices operating at different voltage levels. This versatile component is part of TI's TXS family, known for its robust performance in multi-voltage digital system applications.

Key Features

• Voltage-Level Translation: Enables seamless communication between devices with supply voltages from as low as 1.65V to 5.5V, making it perfect for interfacing between low-voltage microcontrollers and higher voltage peripherals.
• Auto-Direction Sensing: The TXS0104EPWRG4 automatically senses and switches the direction of data flow without the need for a direction control signal, simplifying the design and saving valuable GPIOs.
• Low Standby Current: It features a low standby current, which is ideal for battery-powered and power-sensitive applications.
• ESD Protection: The device includes integrated ESD protection circuits, ensuring robustness and reliability in harsh electrical environments.

Applications

• Mobile Devices
• GPS Navigation Systems
• Data Communication Systems
• Signal Level Translation

Technical Specifications

The TXS0104EPWRG4 is a 4-bit non-inverting translator with two supply rails (VCCA and VCCB) that can be set at any voltage between 1.65V and 5.5V. This device is designed for open-drain and push-pull applications. It also features a power-off circuit that ensures the I/O lines go to a high-impedance state when the device is powered down, preventing any damaging backflow current.

Package and Quality

Encased in a TSSOP-14 package, the TXS0104EPWRG4 is compact and suitable for space-constrained applications. It is also provided in tape and reel form for automated assembly processes. Texas Instruments is known for its commitment to quality, and this product is no exception, meeting strict industry standards for performance and reliability.
