The TLV3402CDR from Texas Instruments is a high-precision dual nanopower comparator that offers ultra-low power consumption and is designed for systems where extended battery life is paramount. This device is part of the TLV340x family of comparators that are optimized for operation with a wide supply range from 1.8V to 5.5V, making them suitable for a variety of battery-operated and portable applications.

Key Features

• Ultra-Low Power Consumption: With a quiescent current of just 470 nA per channel, the TLV3402CDR is an ideal choice for energy-sensitive applications.
• Wide Supply Voltage Range: The device operates over a broad supply voltage range of 1.8V to 5.5V, accommodating a range of power sources and ensuring compatibility with both 3V and 5V systems.
• High Accuracy: Precision design and manufacturing provide excellent input offset voltage and input bias current, ensuring accurate signal detection and comparison.
• Push-Pull Outputs: The TLV3402CDR features push-pull outputs that directly drive either logic levels or loads without the need for external pull-up resistors.
• Fast Response Time: Despite its low power consumption, the device offers a fast response time, which is critical for time-sensitive applications.

Applications

The TLV3402CDR is versatile and can be used in a wide range of applications including:

• Battery-powered devices
• Portable medical equipment
• Power supply control
• Energy harvesting
• Window comparators
• Signal conditioning
• Threshold detectors and system monitors

Package and Quality

The TLV3402CDR is offered in an 8-pin SOIC package, which is compact and suitable for space-constrained applications. Texas Instruments is known for its commitment to quality, and this product is no exception, meeting high standards for reliability and performance.

Ordering Information

To place an order or to obtain more information about the TLV3402CDR, visit the Texas Instruments website or contact an authorized distributor. Ensure you are referencing the correct part number to avoid any confusion with other products in the TLV340x family.
