Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Channels 1, UART
FIFO's 16 Byte
Data Rate (Max) 1Mbps
Supply Voltage - Operating 3 V to 5.25 V
With Auto Flow Control Yes
With False Start Bit Detection Yes
With Modem Control Yes
Mounting SMD (SMT)
Case / Package 48-LQFP (7x7)
Win Source Part Number 032332-TL16C550CIPTR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TL16C550CIPTR CAD Model

Description

Product Overview: TL16C550CIPTR by Texas Instruments

The TL16C550CIPTR is a high-performance, asynchronous communications element (ACE) that seamlessly integrates with a variety of microprocessors and microcontrollers. Manufactured by the renowned Texas Instruments, this component is part of the TL16C550 series, which is known for providing efficient serial communication in a vast array of applications.

Key Features

  • Enhanced Baud Rate: The device offers a programmable baud rate generator that can modulate the baud rate to a wide range of frequencies, ensuring compatibility with various communication standards.
  • FIFO Buffers: With 16-byte FIFOs for transmit and receive, the TL16C550CIPTR can handle high data throughput, reducing CPU overhead and improving system efficiency.
  • Flexible Character Lengths: It supports 5-, 6-, 7-, or 8-bit character lengths, providing versatility in data format and compatibility with numerous communication protocols.
  • Modem Control Capability: The device includes a complete modem control capability, making it suitable for establishing and managing remote connections.
  • Industrial Temperature Range: It operates reliably across a wide temperature range, making it suitable for industrial applications that require robust performance under varying conditions.

Applications

The TL16C550CIPTR is ideally suited for applications that require reliable serial communication. It is commonly used in:

  • Point of Sale (POS) terminals
  • Industrial control systems
  • Networking equipment
  • Telecommunication infrastructure

Package and Quality

Encased in a compact 48-pin LQFP (Low-Profile Quad Flat Package), the TL16C550CIPTR is designed for space-efficient layouts on printed circuit boards. Texas Instruments is committed to delivering high-quality products, and this component is no exception. It meets stringent industry standards for performance and reliability, ensuring that it delivers consistent operation in the most demanding environments.

Conclusion

With its robust feature set and reliable performance, the TL16C550CIPTR from Texas Instruments stands out as a versatile and efficient solution for serial communication needs. Whether it's for industrial automation, networking, or consumer electronics, this ACE is designed to meet the stringent requirements of modern electronic systems.
