The SN74GTL2003RKSR is a state-of-the-art voltage level translator manufactured by Texas Instruments, designed to ensure seamless communication between devices operating at different voltage levels. This device is an essential component in multi-voltage digital system designs, providing a bidirectional interface between any lower voltage logic device and any higher voltage logic device.

Key Features

• Interface Flexibility: With the ability to translate between 0.8V and 5V, the SN74GTL2003RKSR offers versatile interfacing options, making it ideal for a wide range of applications.
• High-Speed Data Transfer: This voltage level translator can support high-speed data transfer, which is critical for modern, high-performance electronic systems.
• Low On-State Resistance: The device features a low on-state resistance (Ron) characteristic, ensuring minimal signal distortion and power loss during translation.
• Flow-Through Pinout: The flow-through design of the pinout simplifies PCB layout by allowing input and output buses to be directly adjacent to one another.

Applications

The SN74GTL2003RKSR is versatile and can be used in various applications, including:

• Mobile Phones
• Tablets
• Notebooks
• Server and Enterprise Solutions
• Networking Equipment
• Consumer Electronics

Product Specifications

Parameter Value Supply Voltage (V<sub>CCA) 0.8V to 3.6V Supply Voltage (V<sub>CCB) 2.3V to 5.5V Operating Temperature Range -40°C to +85°C Package Type 10-VFQFN

With its robust design and compatibility with a wide range of voltage levels, the SN74GTL2003RKSR from Texas Instruments is an excellent choice for designers looking to ensure reliable logic level translation in mixed-voltage environments.
