Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Series
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 1.25V
Output Current 25mA
Tolerance ±0.2%
Temperature Coefficient 75ppm/°C
Noise - 0.1Hz to 10Hz 14μVp-p
Noise - 10Hz to 10kHz 42μVrms
Voltage - Input 1.8 V to 5.5 V
Operating Supply Current 50μA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 027301-REF3012AIDBZR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Portable Devices, Medical, Test & Measurement
Family Name REF3012
Introduction Date February 14, 2005
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian REF3012AIDBZR CAD Model

Description

The REF3012AIDBZR is a high-quality precision voltage reference product from Texas Instruments, a world-renowned American technology company that designs and manufactures semiconductors and various integrated circuits.

  • Output Voltage: Fixed 1.25V output voltage.
  • Quiescent Current: Maximum 50µA.
  • Dropout Voltage: 180mV.
  • Initial Accuracy: 0.2%.
  • Temperature Coefficient: 50ppm/°C.
  • Package: Small SOT-23-3 package.
  • Supply Range: 1.7V to 5.5V.
  • Compliance: RoHS compliant.
