PCA9534DBR Texas Instruments PCA9534DBR Real Image
Same model may have multiple batches, images only for reference.
PCA9534DBR Texas Instruments PCA9534DBR Real Image
PCA9534DBR Texas Instruments PCA9534DBR Real Image
Same model may have multiple batches, images only for reference.

PCA9534DBR

Part No PCA9534DBR
Manufacturer Texas Instruments
Catalog Interface - I/O Expanders
Description IC I/O EXPANDER I2C 8B 16SSOP
Datasheet
PCA9534DBR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of I/O 8
Interrupt Output Yes
Features POR
Output Type Push-Pull
Current - Output Source/Sink 10mA, 25mA
Max Frequency 400kHz
Supply Voltage - Operating 2.3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 134534-PCA9534DBR
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian PCA9534DBR CAD Model

Description

The PCA9534DBR is a high-quality, advanced integrated circuit (IC) designed and manufactured by Texas Instruments, a leading global semiconductor company renowned for its innovative ICs and analog chips.

  • Product: PCA9534DBR
  • Manufacturer: Texas Instruments
  • Description: low-voltage 8-bit I²C and SMBus low-power I/O (input/output) expander
  • Feature: low standby current consumption
  • Operational Range: 2.3V to 5.5V
  • Temperature Range: -40°C to 85°C
  • Function: Expanding the I/O capabilities of microcontrollers and microprocessors that have limited GPIOs (General Purpose Input/Output)
  • Feature: interrupt output
  • Feature: active-low reset input
  • Feature: internal power-on reset function
  • Feature: noise filter on the SCL/SDA inputs
  • Package: small SSOP (Shrink Small Outline Package) 16-pin package
  • Compliance: lead-free and green status
