The Texas Instruments P82B96DGKR is a versatile and robust I²C bus buffer that significantly extends the capabilities of standard I²C communication protocols. Designed for high-speed interfacing on applications requiring long bus lines or the need to interface with multiple devices, this device is a crucial component for engineers and designers working on complex electronic systems.

Key Features

• Extended I²C Bus Range: The P82B96DGKR allows for extended I²C bus lengths, enabling communication over greater distances without compromising signal integrity.
• High-Speed Operation: This device supports fast I²C data rates, making it suitable for high-speed applications that require quick data transfer.
• Bidirectional Signal Translation: It provides bidirectional voltage-level translation between low voltage (down to 2V) and higher voltage (up to 15V) I²C buses without the need for a direction pin.
• Increased Load Capacity: The buffer can support more than 4000 pF of bus capacitance, allowing a higher number of devices to be connected on the same bus.
• Improved Noise Immunity: Its design improves noise immunity, which is especially beneficial in electrically noisy environments or over long cable distances.
• Low Standby Current: With a low standby current, the P82B96DGKR is energy-efficient, making it suitable for battery-powered applications.

Applications

The P82B96DGKR is ideal for a range of applications, including:

• Industrial control systems
• Automotive networks
• Telecommunication infrastructure
• Networking equipment
• Consumer electronics

Package and Quality

Housed in an 8-pin VSSOP package, the P82B96DGKR is designed for surface-mount technology, allowing for compact PCB designs. Texas Instruments ensures high-quality standards, and the device is compliant with RoHS directives, making it suitable for use in environmentally sensitive applications.

With its robust design and advanced features, the Texas Instruments P82B96DGKR is a powerful solution for complex I²C bus systems that demand reliability and performance.
