ISO7240ADWR Real Image ISO7240ADWR Real Image
Same model may have multiple batches, images only for reference.
ISO7240ADWR Real Image ISO7240ADWR Real Image
ISO7240ADWR Real Image ISO7240ADWR Real Image
Same model may have multiple batches, images only for reference.

ISO7240ADWR

Part No ISO7240ADWR
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 4KV 4CH GEN PURP 16SOIC
Datasheet
ISO7240ADWR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Channel Type Unidirectional
Isolation Voltage 4000Vpk
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 1Mbps
Propagation Delay tpLH / tpHL (Max) 95ns, 95ns
Pulse Width Distortion (Max) 10ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002059-ISO7240ADWR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISO7240ADWR CAD Model

Description

The ISO7240ADWR is a high-performance, robust product from Texas Instruments, a leading global semiconductor company.

  • Channels: Quad-channel (two forward, two reverse)
  • Isolation Voltage: Up to 2500 Vrms for one minute per UL1577
  • Data Rate: Up to 150Mbps
  • Supply Voltage Range: 2.7V to 5.5V
  • Temperature Range: -40°C to +125°C
  • Package: Compact 16-pin SOIC package
