INA193AQDBVRQ1 Real Image INA193AQDBVRQ1 label picture INA193AQDBVRQ1 real image INA193AQDBVRQ1 real image110 INA193AQDBVRQ1 Real Image
Same model may have multiple batches, images only for reference.
INA193AQDBVRQ1 Real Image INA193AQDBVRQ1 label picture INA193AQDBVRQ1 real image INA193AQDBVRQ1 real image110 INA193AQDBVRQ1 Real Image
INA193AQDBVRQ1 Real Image INA193AQDBVRQ1 label picture INA193AQDBVRQ1 real image INA193AQDBVRQ1 real image110 INA193AQDBVRQ1 Real Image
Same model may have multiple batches, images only for reference.

INA193AQDBVRQ1

Part No INA193AQDBVRQ1
Manufacturer Texas Instruments
Catalog PMIC - Current Regulation/Management
Description SP Amp Current Shunt Monitor Single 18V Automotive 5-Pin SOT-23 T/R / IC CURRENT MONITOR 3% SOT23-5
Datasheet
INA193AQDBVRQ1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Current Monitor
Sensing Method High-Side
Accuracy ±3%
Voltage - Input -16 V to 80 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 001823-INA193AQDBVRQ1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Power Management, Communications & Networking, Automotive, Motor Drive & Control
Family Name INA193A-Q1
Introduction Date June 01, 2005
Country of Origin China, Malaysia, Thailand
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian INA193AQDBVRQ1 CAD Model

Description

The INA193AQDBVRQ1 is a high-quality, precision current sense amplifier from Texas Instruments, a renowned global semiconductor company.

  • Common-Mode Voltage Range: -16V to +80V
  • Offset Voltage: 2mV (maximum)
  • Gain Error: 1%
  • Bandwidth: 500kHz
  • Package: Small SOT-23
  • Supply Voltage Range: 2.7V to 18V
  • Quiescent Current: 260uA
  • Qualification: AEC-Q100 qualified
  • Protection Features: Short-circuit protection and thermal shutdown
