Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Texas Instruments
Win Source Part Number 1169215-DS26LS32ACMX
Manufacturer Homepage www.ti.com
Family Name DS26LS32AC
Introduction Date January 01, 1996
ECCN EAR99
Country of Origin Malaysia
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DS26LS32ACMX CAD Model

Description

Overview of DS26LS32ACMX from Texas Instruments

The DS26LS32ACMX is a high-performance quad differential line receiver designed to meet the stringent requirements of balanced and unbalanced digital data transmission. Manufactured by Texas Instruments, this device is part of the DS26LS32 series, offering a reliable solution for interfacing with long transmission lines in digital systems. The DS26LS32ACMX is commonly used in applications such as telecommunications, networking, and industrial control systems where signal integrity and noise immunity are critical.

Key Features

  • Multiple Input Options: The device is equipped with four independent differential line receivers, each capable of accepting a wide range of input voltages. This feature allows for flexibility in interfacing with various signal standards.
  • High-Speed Operation: With the capability to support data rates up to 20Mbps, the DS26LS32ACMX is suitable for high-speed data transmission applications.
  • Excellent Noise Immunity: The differential inputs provide improved noise immunity, which is essential for maintaining signal integrity in electrically noisy environments.
  • Wide Operating Range: The receiver operates over a wide supply voltage range of 4.75V to 5.25V, accommodating various system power requirements.
  • Industry-Standard Pinout: The device comes in an industry-standard 16-pin SOIC package, ensuring compatibility with common PCB layouts and ease of integration into existing designs.

Applications

  • Telecommunications systems
  • Data acquisition and signal processing
  • Industrial control and automation
  • Networking equipment
  • Ground loop elimination

Quality and Reliability

The DS26LS32ACMX is built to Texas Instruments' high-quality standards, ensuring reliable performance in a range of environmental conditions. It is characterized for operation from 0°C to 70°C, making it suitable for commercial-grade applications. Additionally, the device is RoHS compliant, adhering to environmental regulations and minimizing the use of hazardous substances in electronic components.

With its robust design, high-speed capabilities, and excellent noise immunity, the DS26LS32ACMX from Texas Instruments stands out as a top choice for system designers looking for a dependable line receiver for their digital communication needs.
