Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Purpose Driver - Fully Integrated, Control and Power Stage
Technology Power MOSFET
Step Resolution 1, 1/2, 1/4, 1/8, 1/16
Applications General Purpose
Output Current 2A
Supply Voltage - Operating 6.5 V to 45 V
Voltage - Load 6.5 V to 45 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 28-HTSSOP
Win Source Part Number 1034181-DRV8880PWPR
Popularity Medium
Supply and Demand Status Limited
Quantity per package 2k pcs
Ultra Librarian 3D Model Ultra Librarian DRV8880PWPR CAD Model

Description

DRV8880PWPR Stepper Motor Driver from Texas Instruments

The DRV8880PWPR is a highly integrated stepper motor driver from Texas Instruments, designed to drive a bipolar stepper motor with advanced features and performance. This compact, power-efficient driver is encapsulated in a 16-HTSSOP package and is particularly suited for applications requiring precise motor control such as printers, scanners, surveillance cameras, and robotics.

Key Features

  • Advanced Current Regulation: The DRV8880PWPR employs an innovative current regulation system that minimizes power consumption and heat generation, allowing for smoother and more efficient motor operation.
  • Smart Tuning: With AutoTune™ technology, the driver dynamically adjusts drive parameters to optimize performance without the need for manual tuning.
  • Versatile Voltage Range: It operates across a wide voltage range from 6.5V to 45V, providing flexibility for various applications and ensuring compatibility with a broad array of stepper motors.
  • Integrated Protection Features: The device includes multiple protection features such as overcurrent, thermal shutdown, and under-voltage lockout, ensuring long-term reliability and safety.
  • Microstepping Support: The DRV8880PWPR supports up to 1/16 microstepping, enabling fine resolution and smoother motion control.
  • Decay Mode Control: Users can select between mixed, slow, and fast decay modes, which allows for better control of the motor based on specific application needs.

Applications

With its robust feature set, the DRV8880PWPR is ideal for a variety of applications that require precise and efficient motor control. Its ability to drive motors with up to 1.5A per phase without a heat sink makes it a versatile choice for compact and embedded systems.

Conclusion

The DRV8880PWPR from Texas Instruments stands out as a sophisticated stepper motor driver solution that combines performance, efficiency, and ease of use. Its AutoTune™ technology, wide voltage range, and integrated protection features make it an excellent choice for designers and engineers looking to enhance their motor control systems. Whether for industrial, commercial, or consumer applications, the DRV8880PWPR offers a reliable and scalable solution for driving stepper motors.
