Products specifications

Manufacturer Texas Instruments
Packaging Reel
Motor Type - Stepper Unipolar
Motor Type - AC, DC Brushed DC
Function Driver - Fully Integrated, Control and Power Stage
Output Configuration Half Bridge (2)
Interface PWM
Technology NMOS
Applications DC Motors, General Purpose, Stepper Motors
Current - Output 3.5A
Supply Voltage (V) 0V ~ 5.5V
Voltage - Load 4.5V ~ 37V
Temperature Range - Operating -40°C ~ 125°C
Mounting Style SMD
Manufacturer Package 16-PowerTSSOP
Supplier Device Package 16-HTSSOP
Manufacturer Pack Quantity 2,000
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Limited
Win Source Part Number 810283-DRV8876PWPR
Ultra Librarian 3D Model Ultra Librarian DRV8876PWPR CAD Model

Description

Introducing the DRV8876PWPR Motor Driver from Texas Instruments

The DRV8876PWPR from Texas Instruments is a highly integrated motor driver solution that is designed to efficiently drive a single brushed DC motor with advanced features and robust performance. This motor driver comes in a compact HTSSOP package, which is ideal for space-constrained applications.

The DRV8876PWPR is capable of delivering up to 3.5A of output current, which makes it suitable for a wide range of applications, from automotive to industrial and consumer electronics. It operates from a supply voltage ranging from 4.5V to 38V, providing the flexibility needed to support various motor specifications and ensuring compatibility with a broad array of power supplies.

One of the key features of the DRV8876PWPR is its integrated current-sensing capabilities, which eliminate the need for external sense resistors and simplify circuit design. It also includes a low-power sleep mode, which significantly reduces power consumption when the motor is not in use, contributing to the energy efficiency of the overall system.

The device offers various control interfaces, including both PHASE/ENABLE and PWM input modes, allowing designers to choose the most suitable control method for their application. Additionally, built-in protection features such as overcurrent, thermal shutdown, and under-voltage lockout ensure the safety and reliability of the motor driver under adverse conditions.

For applications requiring precise motor control, the DRV8876PWPR also includes an advanced current regulation circuit that can be easily programmed via an external reference voltage. This feature provides smooth and accurate motor operation, which is essential in applications where precise speed or torque control is critical.

With its robust integrated features and high performance, the Texas Instruments DRV8876PWPR motor driver is an excellent choice for designers looking to drive a brushed DC motor with confidence and ease. Its high level of integration reduces the need for additional components, enabling compact and cost-effective motor control solutions.
