Same model may have multiple batches, images only for reference.
EV35-5.0-02-3M6 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

EV35-5.0-02-3M6

Part No EV35-5.0-02-3M6
Manufacturer TE Connectivity
Catalog Common Mode Chokes
Description CMC 3.6MH 5A 2LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 3.6 mH @ 400 Hz
Current Rating (Max) 5A
DC Resistance (DCR) (Max) 33mOhm (Typ)
Voltage Rating - AC 250V
Temperature Range - Operating -25°C ~ 100°C
Mounting Type Through Hole
Size / Dimension 1.417" L x 0.965" W (36.00mm x 24.50mm)
Height (Max) 1.681" (42.70mm)
Case / Package Vertical, 4 PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1530553-EV35-5.0-02-3M6
Ultra Librarian 3D Model Ultra Librarian EV35-5.0-02-3M6 CAD Model
