Same model may have multiple batches, images only for reference.
9-1440003-5 Real Image
Same model may have multiple batches, images only for reference.

9-1440003-5

Part No 9-1440003-5
Manufacturer TE Connectivity
Catalog Signal Relays, Up to 2 Amps
Description Electromechanical Relay 24VDC 3.84KOhm 1A SPDT (12.5x7.5x10)mm THT Signal Relay
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Ambient Temperature Range High 85 °C
Coil Current 11.1 mA
Coil Power 200 mW
Coil Resistance 1.44 kΩ
Coil Type Non-Latching
Coil Voltage (DC) 24 V
Contact Current Rating 5 A
Contact Material Silver, Tin
Contact Voltage Rating (AC) 277 V
Current Rating 5 A
Depth 10 mm
Height 15.1892 mm
Lead Free Yes
Length 19.8 mm
Max Current Rating 10 A
Maximum Operating Temperature 70 °C
Max Voltage Rating (AC) 277 V
Max Voltage Rating (DC) 30 V
Min Operating Temperature -40 °C
Mount Through Hole
Number of Contacts 1
Number of Pins 5
Operate Time 10 ms
Radiation Hardening No
Relay Type General Purpose
Release Time 5 ms
RoHS Compliant
Termination PCB
Throw Configuration SPDT
Voltage Rating (AC) 277 V
Weight 7 g
Width 9.9 mm
Win Source Part Number 1084357-9-1440003-5
Categories Signal Relays,Up to 2 Amps
Manufacturer TE Connectivity
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 9-1440003-5 CAD Model

Description

The TE Connectivity 1084357-9-1440003-5 is a signal relay with a current rating of 5 A and a contact material of silver, tin.

  • Contacts: 1
  • Length: 19.8 mm
  • Coil Resistance: 1.44 kΩ
  • Coil Current: 11.1 mA
  • Operate Time: 10 ms
  • Relay Type: General Purpose
  • Coil Type: Non-Latching
  • Release Time: 5 ms
  • Coil Power: 200 mW
  • Throw Configuration: SPDT
  • Mounting: Through-Hole
  • Maximum Operating Temperature: 70 °C
  • Minimum Operating Temperature: -40 °C
  • Lead-Free: Yes
  • RoHS Compliant: Yes
  • Supply and Demand Status: Shortage
