Part No 1825057-3
Manufacturer TE Connectivity
Catalog DIP Switches
Description SWITCH SLIDE DIP SPST 100MA 24V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - DIP Switches
Mfr TE Connectivity
Series ADE
Package Tube
Product Status Active
Circuit SPST
Number of Positions 4
Current Rating (Amps) 100mA
Voltage Rating 24VDC
Actuator Type Slide (Standard)
Actuator Level Raised
Contact Material Copper Alloy
Contact Finish Gold
Height Above Board 0.228" (5.80mm)
Mounting Type Through Hole
Termination Style PC Pin
Pitch 0.100" (2.54mm), Full
Washable Yes
Temperature Range - Operating -30°C ~ 85°C
Body Material Polyphenylene Sulfide (PPS)
Length 0.478" (12.14mm)
Mechanical Life 1,000 Cycles
Electrical Life 1,000 Cycles
Base Product Number 1825057
Standard Package 35 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.50.9065
Win Source Part Number 854207-1825057-3
Ultra Librarian 3D Model Ultra Librarian 1825057-3 CAD Model

Description

The ADE series DIP switch is a 4-position switch with a pitch of 0.100" (2.54mm).

  • Positions: 4
  • Pitch: 0.100" (2.54mm)
  • Termination: PC Pin
  • Contact Finish: Gold
  • Voltage Rating: 24VDC
  • Current Rating: 100mA
  • Height Above Board: 0.228" (5.80mm)
  • Length: 0.478" (12.14mm)
  • Circuit: SPST
  • Actuator Type: Slide, Raised Level
  • Mechanical Life: 1,000 Cycles
  • Electrical Life: 1,000 Cycles
  • Washable: Yes
  • Temperature Range: -30°C to 85°C
  • Manufacturer: TE Connectivity
