The M95010-WDW6TP is a 1-Kbit serial EEPROM product crafted by the renowned semiconductor manufacturer, STMicroelectronics. This EEPROM, which stands for Electrically Erasable Programmable Read-Only Memory, is a non-volatile memory chip that retains data even without power, making it ideal for applications that require data persistence after power-off.
Designed with precision and reliability in mind, the M95010-WDW6TP is part of the M95xxx series, known for its robustness and high performance. This particular model utilizes the standard SPI (Serial Peripheral Interface) bus, ensuring compatibility with a wide range of microcontrollers and processors. It operates over a wide voltage range from 2.5V to 5.5V, which allows for flexibility in various system designs and ensures stable operation under varying power supply conditions.
The M95010-WDW6TP offers a storage capacity of 1 Kbit (128 x 8 bits), which is organized into 16 pages of 8 bytes each. This organization allows for efficient data management and access. Additionally, it features a write cycle time of 5 ms, enabling rapid data storage and quick updates to stored information.
One of the key attributes of this EEPROM is its endurance, with the ability to withstand over 1 million write cycles and a data retention of over 40 years. This endurance guarantees the reliability of the data storage over the product's lifetime. Furthermore, the device supports a wide temperature range from -40°C to +85°C, making it suitable for industrial and automotive applications where extreme conditions are common.
The M95010-WDW6TP comes in an 8-pin TSSOP package, which is known for its compact footprint, making it an excellent choice for space-constrained applications. It also features a hardware write protection pin, which prevents inadvertent write operations to the memory array, thus securing the data integrity.
In summary, the M95010-WDW6TP from STMicroelectronics is a high-quality, durable, and versatile EEPROM chip, perfect for applications that demand reliable and long-term data storage with minimal power consumption.
