STMicroelectronics M25P16-VMF6TP

The M25P16-VMF6TP is a high-performance 16 Mbit (2Mb x 8) serial Flash memory device manufactured by the renowned semiconductor company, STMicroelectronics. This product is designed for a wide range of applications that require data storage and retrieval, including but not limited to, embedded systems, mobile devices, and high-performance industrial applications.

Key Features

• Memory Size: 16 Mbit of Flash memory, organized as 2M x 8 bits, which is ideal for storing firmware, parameters, and data logging.
• Interface: The device operates through a Serial Peripheral Interface (SPI) bus, offering high-speed data transfer.
• Performance: It features a 75 MHz clock frequency, enabling fast read and write operations, which is critical for performance-demanding applications.
• Supply Voltage: The memory operates at a supply voltage range of 2.7V to 3.6V, making it suitable for low-power applications.
• Programmable: Users can program the memory in 256-byte pages or erase in 4 KB, 32 KB, or 64 KB blocks, providing flexibility in managing data.
• Temperature Range: The device is designed to operate over an industrial temperature range from -40°C to 85°C.
• Package: Supplied in an 8-pin, ultra-thin, fine pitch package (VFQFPN), which is both space-saving and suitable for PCBs with limited real estate.

Applications

The M25P16-VMF6TP is versatile, catering to a diverse set of applications such as:

• Advanced mobile devices
• Embedded microcontrollers
• Digital cameras and other portable devices
• Networking and telecommunications equipment
• Automotive systems
• Industrial automation systems

Reliability and Support

STMicroelectronics ensures that the M25P16-VMF6TP meets the highest quality and reliability standards. The company provides comprehensive technical support and documentation, making integration and development with the M25P16-VMF6TP straightforward for engineers and product developers.

Note: For detailed technical specifications, application notes, and support documentation, please refer to the official STMicroelectronics website or contact their support team.
