The M24512-DFCS6TP/K is a 512-Kbit I²C-compatible EEPROM (Electrically Erasable Programmable Read-Only Memory) produced by STMicroelectronics. This device is part of ST's M24 series of high-speed, I²C serial interface EEPROMs. It is particularly suitable for a wide range of applications that require data storage that can be modified in operation, including industrial, automotive, and consumer electronics.

Key Features

• Memory Size: 512 Kbits of EEPROM memory, organized as 64 Kbytes of 8 bits each, providing ample space for user data storage.
• Interface: Two-wire I²C serial interface supports 400 kHz protocol, allowing for easy integration into most microcontroller-based systems.
• Write Cycle Time: Fast write cycle time of 5 ms max, with byte and page write modes (up to 128 bytes) for efficient data handling.
• Operating Voltage Range: Wide power supply voltage range from 1.8 to 5.5 V, making it compatible with both 3.3 V and 5 V systems.
• Temperature Range: Industrial temperature range from -40°C to +85°C, ensuring reliable operation under extreme conditions.
• Write Protect: Hardware write control is available via the WC (Write Control) pin to prevent inadvertent data changes.
• Endurance: High reliability with 1 million write cycles and 40-year data retention, ensuring the longevity of stored data.
• Package: The device comes in an ultra-thin 8-pin UFDFPN package, which is RoHS compliant and suitable for space-constrained applications.

Applications

The M24512-DFCS6TP/K EEPROM is versatile and can be used in various applications such as:

• Parameter storage for industrial applications.
• Configuration and setup memory for consumer electronics.
• Non-volatile memory for automotive systems.
• Calibration data storage for various sensors and instruments.

With its robust design and flexible features, the M24512-DFCS6TP/K EEPROM from STMicroelectronics is an excellent choice for designers looking for a reliable and high-performance data storage solution.
