Same model may have multiple batches, images only for reference.
80MXC4700MEFCSN30X40 Rubycon
Same model may have multiple batches, images only for reference.

80MXC4700MEFCSN30X40

Part No 80MXC4700MEFCSN30X40
Manufacturer Rubycon
Catalog Aluminum Capacitors
Description CAP ALUM 4700UF 20% 80V SNAP / 4700 µF 80 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In 3000 Hrs @ 105°C
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors - Aluminum Electrolytic Capacitors
Mfr Rubycon
Series MXC
Package Bulk
Product Status Active
Capacitance 4700 µF
Tolerance ±20%
Voltage - Rated 80 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 3000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 3.38 A @ 120 Hz
Ripple Current @ High Frequency 3.887 A @ 10 kHz
Lead Spacing 0.394" (10.00mm)
Size / Dimension 1.181" Dia (30.00mm)
Height - Seated (Max) 1.654" (42.00mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0040
Win Source Part Number 1360784-80MXC4700MEFCSN30X40
Ultra Librarian 3D Model Ultra Librarian 80MXC4700MEFCSN30X40 CAD Model

Description

The Rubycon MXC series aluminum electrolytic capacitor is a general-purpose component suitable for a wide range of applications.

  • Capacitance: 4700µF
  • Voltage Rating: 80V
  • Tolerance: ±20%
  • Temperature Range: -40°C to 105°C
  • Package: Radial, Snap-In Can-Style
  • Mounting Type: Through Hole
  • Size: 1.181" diameter
  • Height: 1.654"
  • Lifetime: 3000 hours @ 105°C
  • Ripple Current @ Low Frequency: 3.38A @ 120Hz
  • Ripple Current @ High Frequency: 3.887A @ 10kHz
