Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Not For New Designs
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 30V
Current - Average Rectified (Io) 1.5A
Voltage - Forward (Vf) (Max) @ If 490mV @ 1.5A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 50μA @ 30V
Mounting SMD (SMT)
Case / Package PMDU
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 027102-RB070M-30TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name RB070M-30
Introduction Date June 09, 2005
ECCN EAR99
Halogen Free Not Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian RB070M-30TR CAD Model

Description

The Rohm Semiconductor RB070M-30TR is a diode type Schottky with a maximum DC reverse voltage of 30V and an average rectified current of 1.5A.

  • Maximum DC Reverse Voltage: 30V
  • Average Rectified Current: 1.5A
  • Voltage Forward (Vf) (Max) @ If: 490mV @ 1.5A
  • Current Reverse Leakage @ Vr: 50μA @ 30V
  • Capacitance @ Vr, F: Not specified
  • Operating Temperature Range: 150°C (Max)
  • Speed (Frequency): Fast recovery = 200mA (Io)
  • Package: Reel - TR
  • Mounting: SMD (SMT)
  • Part of Family: RB070M-30
  • Categorized as: Discrete semiconductor product
  • ECCN: EAR99
  • Estimated EOL date: 2022
  • Introduction Date: June 09, 2005
  • Supply and Demand Status: Balanced
  • Alternative Parts: RB070MM-30TFTR, RB070MM-30TF, RB070M-30TFTR, CRS09(TE85L,SHRP,Q;)
