SPA-2118Z RF Micro Devices SPA-2118Z Real Image1 SPA-2118Z Real Image2 SPA-2118Z Real Image3
Same model may have multiple batches, images only for reference.
SPA-2118Z RF Micro Devices SPA-2118Z Real Image1 SPA-2118Z Real Image2 SPA-2118Z Real Image3
SPA-2118Z RF Micro Devices SPA-2118Z Real Image1 SPA-2118Z Real Image2 SPA-2118Z Real Image3
Same model may have multiple batches, images only for reference.

SPA-2118Z

Part No SPA-2118Z
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description IC AMP HBT GAAS 850MHZ 8-SOIC / RF Amp Single Power Amp 960MHz 5.25V 8-Pin SOIC EP
Datasheet
SPA-2118Z Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RFMD
Packaging Reel package
Part Status Obsolete(EOL)
Frequency 810MHz ~ 960MHz
P1dB 29dBm (794.3mW)
Gain 31.5dB ~ 34.5dB
Noise Figure 5dB
RF Type ISM, IS-95, CDMA, AMPS
Operating Supply Voltage 4.75 V ~ 5.25 V
Operating Supply Current 360mA ~ 425mA
Test Frequency 900MHz
Package 8-SOIC (0.154", 3.90mm Width) Exposed Pad
Manufacturer Package 8-SOIC
Win Source Part Number 795281-SPA-2118Z
Popularity Medium
Supply and Demand Status Limited
Family Name SPA-2118
Introduction Date November 21, 2002
ECCN 5A991.g
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian SPA-2118Z CAD Model

Description

RFMD SPA-2118Z is a 900MHz RF amplifier.

  • Gain: 31.5dB ~ 34.5dB
  • Noise Figure: 5dB
  • P1dB: 29dBm (794.3mW)
  • RF Types: ISM, IS-95, CDMA, AMPS
  • Test Frequency: 900MHz
  • Frequency Range: 810MHz ~ 960MHz
  • Package: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Operating Supply Voltage: 4.75 V ~ 5.25 V
  • Status: Obsolete (EOL), limited supply and demand
